    Moderator iGO Speedcam (DISCUSSION)
    iGO Speedcam (DISCUSSION)
    Andrey Form's Avatar
    Join Date
    Oct 2019
    Location
    Belarus
    Posts
    724
    Rep Power
    1277

    autovelox iGO Speedcam (DISCUSSION)

    iGO Speedcam (DISCUSSION)
    speedcam iGO
    speedcam iGO skin Primo/ NextGen/ Luna


    FAQ briefly in fact
    Spoiler: +
    For iGO Primo (NextGen) Luna *.txt put files in a folder content/speedcam
    Before the update we do not delete it file speedcam.spdb.
    File speedcam.spdb updated every time iGO is started.
    Large files speedcam.txt they can be loaded at the first start iGO very long on weak devices, Win CE.
    Radars do not beep and are not notified in the simulation, but are only visible on the map.


    X,Y - coordinates (longitude, latitude).

    TYPE - camera type

    SPEED

    In iGO there are three options for displaying the speed when warning:
    - speed in the file;
    - the permissible speed on the section of road on which you are moving;
    - no speed at all.

    X,Y,TYPE,SPEED,DIRTYPE,DIRECTION
    48.057311,46.347428,1,60,1,121 - speed in the file
    48.057311,46.347428,1,0,1,121 - speed from the map
    48.057311,46.347428,1,,1,121 - without speed

    DIRTYPE - how many directions does the camera work in: In all=0; In one=1; Both ways =2:

    X,Y,TYPE,SPEED,DIRTYPE,DIRECTION
    48.057311,46.347428,1,60,1,121 - In one
    48.057311,46.347428,1,60,2,121 - Both ways
    48.057311,46.347428,1,60,0,121 - In all

    DIRECTION - the direction of movement of the car: North=0; East=90; South=180; West=270. By DIRTYPE=0 this parameter has no value.

    Format speedcam.txt

    X,Y,TYPE,SPEED,DIRTYPE,DIRECTION or IDX,X,Y,TYPE,SPEED,DIRTYPE,DIRECTION

    iGO does not read IDX, for this reason, which speedcam.txt format does not affect the operation of iGO

    What additional entries can speedcam.txt
    Signature, point comments

    All signatures and comments, only after the comma
    X,Y,TYPE,SPEED,DIRTYPE,DIRECTION, <signatures>
    20.555555,30.777777,1,90,1,180, <comments>

    fake
    X,Y,TYPE,SPEED,DIRTYPE,DIRECTION;
    20.555555,30.777777,1,90,1,180, <comments>

    These characters must not be in the string (: ; // > etc.)
    This results in a circular alert, DIRTYPE =1 or =2
    become DIRTYPE =0

    IDX,X,Y,TYPE,SPEED,DIRTYPE,DIRECTION
    0,20.555555,30.777777,1,90,1,180

    IDX,X,Y,TYPE,SPEED,DIRTYPE,DIRECTION;
    0,20.555555,30.777777,1,90,0,180



    AND
    FAQ speedcam in iGo
    Spoiler: +
    I have long wanted to explain the use of speedcam in iGo.

    spc-speedcam, that is, speedcam in encrypted format
    spc-not signed in spdb
    spc-consists of the main types of cameras with directional signaling
    spc-after * ASC has only the first camera-start
    spc-after coordinate matching has an advantage over speedcam.txt

    Speedcam.txt - local dangerous points
    Speedcam.txt-saved in spdb

    Using * spc from two manufacturers at the same time (TomTom, HERE) increases the alarm points by * twice
    Pay attention to the date of creation of the spc, it is possible that the value of many points no longer matters.
    use any speedcam.spc, from HERE or TomTom. IGO it doesn't matter who does the spc.

    Using * spc in combination with * txt
    Perhaps it all depends on the user's desire, which leads to a doubling of the alarm points.

    * ASC-Average Speed Camera
    * twice-a relative indicator (the coordinates of two different bases are unlikely to coincide)
    * ASC-use one set of start-finish when working with the pongo, wandel skin, so as not to disrupt the notification system with false positives from duplicates.

    Two medium speed cameras, no more than that:
    the first (beginning of the zone) with a measurable limit, for example 80km / h
    the second (end of the zone) with a speed limit of 5km / h,

    SpedcamUpdates.spud
    saves all added from the navigator screen speedcam
    SpedcamUpdates.spud the file is stored
    iGO_Luna-->privdocs--->InappShop--->Mount--->speedcam--->SpedcamUpdates.spud
    NextGen iGO_XXX-->privdocs--->InappShop--->Mount--->speedcam--->SpedcamUpdates.spud



    [Only registered and activated users can see links. ]

    Dear friends, Discussion brings a solution to the issue. BUT ! If you showed a movie, screenshots, but did not explain what you did for such a result, then your help is zero. If your advice was not confirmed on other devices, then your help is zero. I understand that with modern technical equipment, it is possible to make any installation, which may lead to confusion. Let's just say that any ostentatious post without explaining the actions is a flood in this topic.

    I hope this will help to understand any questions without clogging up the topic with empty posts

    [Only registered and activated users can see links. ]

    [Only registered and activated users can see links. ]


    Last edited by Andrey Form; 1st February 2023 at 08:40 AM.
    gps5

    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]


    ©AF_2020-23

  2.    Advertissements


  3. #2
    Master kwbs's Avatar
    Join Date
    Jul 2017
    Location
    IL
    Posts
    789
    Rep Power
    121

    Default

    Hellow @Andrey Form

    I see that the spcam's codes in your files are different from the codes i'm familiar with.

    Here are two examples:

    Cyprus
    X,Y,TYPE
    33.411033,33.417615,50,60,0,230
    33.59136,35.20797,32,60,1,96

    Which type of cam is 50? 32?

    Slovakia
    X,Y,TYPE
    17.036038,48.211966,35,5,1,337
    21.301739,48.805577,42,50,1,173
    21.585302,49.300865,51,60,2,357
    21.569466,49.221998,52,40,1,140

    Which type of cam is 35? 42? 51? 52?


    Can you please write down here your codes list and cameras which associated with them?

  4. #3
    Moderator iGO Speedcam (DISCUSSION)
    iGO Speedcam (DISCUSSION)
    Andrey Form's Avatar
    Join Date
    Oct 2019
    Location
    Belarus
    Posts
    724
    Rep Power
    1277

    Amigo

    Quote Originally Posted by kwbs View Post
    Hellow @Andrey Form
    I see that the spcam's codes in your files are different from the codes i'm familiar with.
    CODE iGO Full

    Spoiler: 32

    _ID0 = 1_or_64_or__96_or_128_or_160_or_192_or_224 - 32
    _ID1 = 5_or_65_or__97_or_129_or_161_or_193_or_225 - 33
    _ID2 = 2_or_66_or__98_or_130_or_162_or_194_or_226 - 34
    _ID3 = 4_or_67_or__99_or_131_or_163_or_195_or_227 - 35
    _ID4 = 3_or_68_or_100_or_132_or_164_or_196_or_228 - 36
    _ID5 = __or_69_or_101_or_133_or_165_or_197_or_229 - 37
    _ID6 = 6_or_70_or_102_or_134_or_166_or_198_or_230 - 38
    _ID7 = 7_or_71_or_103_or_135_or_167_or_199_or_231 - 39
    _ID8 = 8_or_72_or_104_or_136_or_168_or_200_or_232 - 40
    _ID9 = 9_or_73_or_105_or_137_or_169_or_201_or_233 - 41
    ID10=10_or_74_or_106_or_138_or_170_or_202_or_234 - 42
    ID11=11_or_75_or_107_or_139_or_171_or_203_or_235 - 43
    ID12=12_or_76_or_108_or_140_or_172_or_204_or_236 - 44
    ID13=13_or_77_or_109_or_141_or_173_or_205_or_237 - 45
    ID14=14_or_78_or_110_or_142_or_174_or_206_or_238 - 46
    ID15=15_or_79_or_111_or_143_or_175_or_207_or_239 - 47
    ID16=16_or_80_or_112_or_144_or_176_or_208_or_240 - 48
    ID17=17_or_81_or_113_or_145_or_177_or_209_or_241 - 49
    ID18=18_or_82_or_114_or_146_or_178_or_210_or_242 - 50
    ID19=19_or_83_or_115_or_147_or_179_or_211_or_243 - 51
    ID20=20_or_84_or_116_or_148_or_180_or_212_or_244 - 52
    ID21=21_or_85_or_117_or_149_or_181_or_213_or_245 - 53
    ID22=22_or_86_or_118_or_150_or_182_or_214_or_246 - 54
    ID23=23_or_87_or_119_or_151_or_183_or_215_or_247 - 55
    ID24=24_or_88_or_120_or_152_or_184_or_216_or_248 - 56
    ID25=25_or_89_or_121_or_153_or_185_or_217_or_249 - 57
    ID26=26_or_90_or_122_or_154_or_186_or_218_or_250 - 58
    ID27=27_or_91_or_123_or_155_or_187_or_219_or_251 - 59
    ID28=28_or_92_or_124_or_156_or_188_or_220_or_252 - 60
    ID29=29_or_93_or_125_or_157_or_189_or_221_or_253 - 61
    ID30=30_or_94_or_126_or_158_or_190_or_222_or_254 - 62
    ID31=31_or_95_or_127_or_159_or_191_or_223_or_255 - 63
    Last edited by Andrey Form; 31st May 2022 at 07:50 PM.
    gps5

    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]


    ©AF_2020-23

  5. #4
    Member + iGO Speedcam (DISCUSSION)
    Join Date
    Mar 2018
    Location
    ohio
    Posts
    67
    Rep Power
    0

    autovelox

    Andrey Form i read allot of your speed cam stuff and have a few question if you can answer.

    Here in usa there is not many resorces for alert points like im seeing for europe. we can get a basic speed cam file but it doesnt have many mobile speed cams with mostly red light camera. i am running Luna Mod Garigor which from reading is a mod from the pongo skin. here are my question as i have yet to get mobile speedcams to work. i do see some redlight cameras if i use scdb txt but i dont think any show with my custom speed.txt.

    1. Here is an example of some of my speed text entries

    X,Y,TYPE,SPEED,DirType,Direction
    -81.63950,41.50700,1,0,0,0
    -77.01399,38.89646,1,0,0,0
    -77.18203,39.07650,1,0,0,0
    -77.09079,39.05343,1,0,0,0
    -77.06599,39.05919,1,0,0,0
    -77.16354,39.08496,1,0,0,0
    -81.65503,41.50596,1,0,0,0
    -77.00489,38.92840,1,0,0,0
    -77.19700,39.25290,1,0,0,0
    -77.28207,39.10753,1,0,0,0

    Do these look ok to work with my luna version i have?

    2. Is there a limit on the number of speedcams you can have in a txt file? i beleive i have alittle under 20k

    3. Did the speedcams type change in the luna version? example 1 is supose to be moble speedcams and 4 is suppose to be redlight.

    trying to narrow down whats wrong with speedcams on my luna version. i have the speedcam ux that cam with the mod. i dont understand why the scdp works but my custum one doest. even if i just have 10 entries of known points they dont show up. the scdb is pretty much useless around me as it has none in my 50 mile radious and mostly just red light cams.
    Last edited by Andrey Form; 31st May 2022 at 06:50 PM.

  6. #5
    Moderator iGO Speedcam (DISCUSSION)
    iGO Speedcam (DISCUSSION)
    Andrey Form's Avatar
    Join Date
    Oct 2019
    Location
    Belarus
    Posts
    724
    Rep Power
    1277

    Default

    @badwhip
    There are no differences in the speedcam codes for Luna, NextGen, Primo. Codes are assigned by type in speedcam.zip. Speedcam file size limits.txt no.

    Use 32 -63 encoding, there will be no confusion as it happens in 1-32
    Last edited by Andrey Form; 20th December 2021 at 07:17 AM.
    gps5

    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]


    ©AF_2020-23

  7. #6
    Master spyder's Avatar
    Join Date
    Jan 2016
    Location
    Esperia
    Posts
    1,147
    Rep Power
    1126

    Default

    The speedcam(USA) txt is OK (tested)
    I've deleted a few duplicates
    Attached Files Attached Files
    Last edited by spyder; 22nd June 2021 at 06:08 PM.

  8. #7
    Moderator iGO Speedcam (DISCUSSION)
    iGO Speedcam (DISCUSSION)
    Andrey Form's Avatar
    Join Date
    Oct 2019
    Location
    Belarus
    Posts
    724
    Rep Power
    1277

    Default

    iGO's achievements in the field of speedcam, encoding Default Luna
    Spoiler: +
    [0] = "StaticCamera",
    [1] = "MobileCamera",
    [2] = "CameraInTrafficLight",
    [3] = "SectionCamera",
    [4] = "RedLight",
    [5] = "Not_Used",
    [6] = "RailwayCrossing",
    [7] = "BusLane",
    [8] = "BlackSpot",
    [9] = "SchoolZone",
    [10] = "UrbanArea",
    [11] = "RedLightTrap",
    [12] = "TollBooth",
    [13] = "Hospital",
    [14] = "FireStation",
    [15] = "ChargeZone",
    [16] = "type_16",
    [17] = "type_17",
    [18] = "type_18",
    [19] = "type_19",
    [20] = "type_20",
    [21] = "type_21",
    [22] = "SpeedBump",
    [23] = "NoParkingZone",
    [24] = "type_24",
    [25] = "type_25",
    [26] = "type_26",
    [27] = "type_27",
    [28] = "type_28",
    [29] = "type_29",
    [30] = "type_30",
    [31] = "DangerousArea"

    And it seems there are differences in the code number
    [22] = "SpeedBump", skin [18] = "Speed Breaker"
    [23] = "NoParkingZone", skin [24] = "Stop Prohibited Camera"

    Databases and codes of Bulgaria and Greece, these two databases (data collection sites) do not collect the following codes

    Spoiler: BG

    not in the database - Х

    [Only registered and activated users can see links. ]

    Spoiler: GR

    not in the database - Х

    [Only registered and activated users can see links. ]


    As a result of comparing databases, they do not collect information about the following codes
    [24] = Dangerous Railroad Crossing
    [25] = Highway Exit
    [26] = Speed Boards
    [27] = Dynamic Traffic Light
    [28] = Max Height
    These codes are not collected by databases and are not systematically updated, they are individual accumulations
    Last edited by Andrey Form; 20th December 2021 at 07:19 AM.
    gps5

    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]
    [Only registered and activated users can see links. ]


    ©AF_2020-23

  9. #8
    Master spyder's Avatar
    Join Date
    Jan 2016
    Location
    Esperia
    Posts
    1,147
    Rep Power
    1126

    Default

    Quote Originally Posted by badwhip View Post
    Spyder this is what interesting. I donít believe I see the red light or speed cameras from your files. I loaded in content/poi amd content/usericon would I see these in the search menu too? . ... Is there anyway to have a custom poi with a red light camera anywhere near cincinnati Ohio 45252 area because if I see one show up there I know it works. ....
    You have to simply overwrite posted content folder to existing content folder in your device. Then in map settings/poi settings the new icons are visible to eneble/disable.

    Unfurtunately in Cincinnati there is no speedcam in database, only two near New Richmond

    Spoiler: Map
    [Only registered and activated users can see links. ]
    Last edited by Boki_Srb; 30th June 2021 at 04:48 PM. Reason: quote shortened

  10. #9
    Master LouBouha's Avatar
    Join Date
    Mar 2017
    Location
    Tunisia
    Posts
    465
    Rep Power
    1253

    Default USA SpeedCams

    It seems that speedcams in the US and Canada are visible according to the state code

    Spoiler: Code
    Code:
    Please Login or Register to see the links


    try to enter the sys.txt

    Spoiler: sys.txt
    Code:
    Please Login or Register to see the links


    Regards
    GPS: TomTom ONE

    Smartphone: THL T11 Android 4.2.2 Resolution 720x1280
    Sygic 14.3.4 IGO Primo 9.6.29.636868 Skins : Doupas V9.0h , Dimka/Frontzosd giphy

  11. #10
    Master iGO Speedcam (DISCUSSION)iGO Speedcam (DISCUSSION)
    Join Date
    Nov 2017
    Location
    europa
    Posts
    71
    Rep Power
    137

    Default

    this is mainly only of importance for the display style of certain road signs

    spr_speedlimit_eu.bmp [Only registered and activated users can see links. ] spr_speedlimit_usa.bmp [Only registered and activated users can see links. ]
    Last edited by lunapark; 1st July 2021 at 05:58 PM.





Tags for this Thread

Bookmarks

Posting Permissions

  • You may not post new threads
  • You may not post replies
  • You may not post attachments
  • You may not edit your posts
  •
